| Capability |
|
| Total Channels |
360 |
| Max. LTP Channels |
360 |
| Max. HTP Channels |
360 |
| DMX Dimmers |
1024 |
| intelligent Lamps |
250 |
| lamp Tyres |
256 |
| |
|
| Internal Storage |
|
| Total Cues |
1000 |
| Integer Cues |
800 |
| Decimal Cues |
200 |
| Sequences |
100 |
| Steps/Sequence |
99 |
| |
|
| Preset |
|
| Preset Controls |
30 |
| Control type |
Digital Fader |
| Preset Scrolling |
Yes |
| |
|
| Playback |
|
| Cue Controls |
30 submasters |
| Control Type |
Digital fader |
| Stack/list Controls |
1 Playback |
| Playback Type |
Split Fader |
| Sequence Controls |
3 Playbacks |
| Control Type |
Digital Fader |
| |
|
| Physical |
|
| Height(h) |
286mm |
| Depth (d) |
950mm |
| Length (w) |
1054mm |
| Weight |
57kg |
| |
|
| Electrical |
|
| PSU Type |
Ext. Switching |
| Supply Voltage |
80-240 V 50/60 Hz |
| Supply Current |
2A |
| No. of PSU's |
1 |
